Protect Engine Oil & Performance With an AOS
Share
If you own a 2015+ WRX, your FA20 DIT engine has a specific vulnerability. It is direct-injected: fuel sprays straight into the cylinder and never washes over the intake valves. Nothing cleans them. Oil blow-by does the opposite — it coats them, and the coating bakes into carbon that restricts airflow and costs power. An air oil separator (AOS) stops the oil before it gets there. It is engine protection, not a power part.
What Does an Air Oil Separator Do for Your WRX?
Under normal operation the engine builds crankcase pressure, and that pressure carries a mix of air and oil vapor. Without an AOS, the oily mist recirculates into the intake. It coats the intercooler and cuts its cooling efficiency. It mixes with fuel in the combustion chamber and lowers the effective octane, which raises the risk of detonation — uncontrolled combustion that can damage pistons and cylinder walls.
An AOS intercepts the crankcase gases before they reach the intake manifold. Inside, baffles separate the heavier oil droplets from the air. Clean air goes back to the intake. The collected oil returns to the engine's oil pan. That one process prevents carbon buildup on the intake valves, keeps oil out of the intercooler, and keeps the fuel's octane where it belongs.
Crawford developed the original closed-loop Subaru AOS. The Crawford unit is aluminum, made in the USA with USA components, and it returns separated oil to the crankcase automatically. There is nothing to drain and nothing to service on a schedule.
One compliance note, stated plainly: the Crawford AOS carries no CARB EO. Check the EO status for your application before you buy.
Is an AOS Really Necessary for Your WRX?
Yes — stock or modified. Every turbocharged boxer produces blow-by. On a port-injected engine, fuel washing over the valves limits what the oil can build. The FA20 DIT has no such wash. Left alone, the valves collect carbon, the intercooler collects oil, and the engine runs on a dirtier charge than it was tuned for. An AOS is a foundational part: it protects the engine every other part depends on. Install it before you add power, not after something fails.
The Real-World Benefits
Stops carbon buildup. Oil vapor kept out of the intake cannot bake onto the valves. Airflow stays open, and the detonation risk that comes with oil in the combustion chamber drops with it.
Maintains performance and extends engine life. An engine running on clean air holds its octane rating and its tune. Oil pooling in the intercooler, coating sensors, and degrading rubber hoses is oil that never got there. The protection compounds over the life of the car.
Keeps the oil charge clean. The AOS addresses contamination at the source, before vapor enters the intake system at all. What stays out cannot degrade anything downstream.
Beyond the AOS: Motor Oil Still Matters
An AOS handles oil vapor. The oil itself still does the rest of the work: managing heat, carrying contaminants to the filter, and keeping a protective film on bearings, cams, and cylinder walls under load. A turbocharged engine works its oil hard. Run a quality full-synthetic oil, keep to the change schedule, and shorten the interval if the car is tracked or driven hard. No oil, however good, cleans intake valves on a direct-injection engine — that is the AOS's job, and the two are not interchangeable.
AOS vs. Catch Can: Which Is Right for Your WRX?
Both devices intercept the same blow-by. They differ in what happens to the oil.
A catch can collects it in a reservoir and holds it. You drain the reservoir by hand, on a schedule, forever. Forget, and the can fills and stops working.
An AOS is a closed loop. It separates the oil and returns it to the crankcase automatically. There is no reservoir and no draining. One honest trade-off: because the AOS returns oil to the engine, trace amounts of fuel and water vapor can return with it. A catch can traps everything — but only while it is being emptied. For a car that gets driven daily and maintained on a normal schedule, the closed loop is the system that keeps working when you are not thinking about it. Crawford does not sell catch cans. The AOS is the answer we build.
How to Spot a Quality WRX Air Oil Separator
The return mechanism. Automatic return to the crankcase is the defining feature. If it has a cup you empty, it is a catch can, whatever the label says.
Build quality and materials. The unit lives in heat and pressure and breathes oil and fuel vapor. Billet aluminum holds up; hoses and fittings must resist oil and fuel without cracking or degrading. The Crawford AOS is built from aluminum for exactly this environment.
Separation design. Look for a proven separation method and a design that prevents oil from pooling or sloshing, so separation stays consistent under hard cornering and acceleration.
Model-specific fit. A unit engineered for your WRX model year comes with the right brackets, hoses, and fittings. Universal kits invite leaks and guesswork. A proper fit is a straightforward, leak-free installation.
More detail is in our AOS guide, and the WRX fitments sit in the WRX upgrades collection.
WRX AOS Installation: What to Watch Out For
Instructions vs. your engine bay. Subaru makes small changes between model years; a vacuum line or mounting point may sit somewhere the instructions do not show. Some 2009 WRX owners found their engine bay matched the 2008 instructions. Confirm your model, use the instructions as a guide, and trust what is in front of you.
Hose routing. The WRX engine bay is crowded. Route each hose clear of the turbocharger and other heat sources, with no sharp bends or kinks to obstruct flow. Secure lines with zip ties so nothing rubs.
DIY or professional. A straightforward car and a patient installer: a weekend project. A heavily modified engine, clearance problems with a larger intercooler, or no appetite for troubleshooting mid-job: have a professional install it. The installation is the step that decides how the system performs.
3 Common WRX AOS Myths, Busted
"An AOS is only for race cars." Every direct-injection WRX produces blow-by, including a stock daily driver. The carbon builds more slowly, but it builds. An AOS is preventative maintenance, not a race part.
"AOS systems are high-maintenance." The opposite. A closed-loop AOS has no reservoir to empty and no service interval. A catch can is the one that adds a recurring task.
"An AOS is just an expensive catch can." A catch can holds oil. An AOS separates oil and returns it to the crankcase. Different mechanism, different upkeep, different result.
Maintaining a WRX AOS
There is very little to maintain, and that is the point. Every few months, or at each oil change, look the system over: hoses for cracking, brittleness, or loose fittings; the body and drain lines for leaks. Secure connections keep the loop closed. For most drivers no internal cleaning is ever needed. If you track the car frequently or live in an extremely cold climate, check the drain lines occasionally for sludge.
Warning signs that separation is no longer working: a sudden increase in oil consumption, blue smoke from the exhaust, or oil residue in the intercooler or intake piping. Investigate early.
Does Your Specific WRX Model Need an AOS?
2002–2014 WRX. The EJ-series engines are durable and still susceptible to blow-by. Oil vapor coats intake valves and pistons over time and costs power and efficiency. An AOS intercepts it at the source, and a quality system should keep the intake valves from needing a deep cleaning for the life of the engine.
2015+ WRX. The FA20 DIT makes the AOS essential rather than recommended. Direct injection removed the fuel wash that port injection gave the valves, so blow-by has an open path to bake on. Stopping the oil before it reaches the valves is the only fix that addresses the cause.
Your Checklist for Choosing an AOS
- Driving style. Hard use and track time produce more blow-by and call for high separation efficiency. Daily driving produces the same buildup, slower.
- Budget. An AOS is insurance priced against engine work. A cheap unit that separates poorly buys the problems you were avoiding.
- Install. DIY if you are comfortable in a tight engine bay. Professional installation if you are not. Either way, the fit has to be right the first time.
Frequently Asked Questions
Is an AOS really necessary if my WRX is completely stock? Yes. A stock engine produces blow-by from the first mile. The AOS is preventative care, not a high-horsepower part.
Will installing an AOS increase my horsepower? No. An AOS adds no power. It prevents the losses — carbon buildup, a fouled intercooler, reduced octane — that take power away over time.
What's the main reason to choose an AOS over a less expensive catch can? The closed loop. A catch can must be drained by hand and stops working when it fills. An AOS returns the oil to the engine automatically and keeps working.
Do I have to empty or drain an air oil separator? No. There is no reservoir. Separated oil drains back into the engine on its own.
Why is an AOS so important for the 2015+ WRX? Direct injection. Fuel never washes the intake valves, so oil blow-by is the whole carbon story, and an AOS is what stops the oil from reaching them.
