Subaru Cylinder Heads: The Ultimate Owner's Guide

An engine is an air pump. Its power is limited by how well it breathes, and the cylinder heads control the breathing. Bolt-ons get you only so far. Past that point, the heads decide what the engine can do — and whether it survives doing it.

This guide covers how Subaru heads work, how they fail, what the failures cost, and when a head is worth rebuilding, resurfacing, or replacing outright.

What a Cylinder Head Does

The cylinder heads sit on top of the block and seal the combustion chambers. They hold the valves, camshafts, and spark plugs. They control the flow of the air-fuel mixture in and the exhaust gases out.

Head design and condition affect power, efficiency, and engine life. A head that flows well makes power. A head that manages heat well lasts. Both matter more as power goes up.

SOHC vs. DOHC

Subaru uses two head layouts. SOHC (single overhead cam) means one camshaft per head. DOHC (double overhead cam) means two.

DOHC layouts typically run four valves per cylinder. More valve area means better breathing at high RPM. That is why the WRX and STI use DOHC heads. SOHC heads are simpler and show up in economy and non-turbo models, where peak power is not the goal.

EJ vs. FA Heads

The EJ series powered the WRX and STI from 2002 through 2021 for the STI. The FA series arrived in newer models, including the WRX from 2015 to the present.

EJ and FA heads are not interchangeable. Bolt patterns, port designs, and combustion chamber shapes are all different, tailored to each block. The FA head was designed around direct injection, which changed the layout completely. Confirm the engine series before you buy anything.

Turbocharging Raises the Stakes

A turbo forces far more air into the engine. Cylinder pressures and temperatures climb with it. Stock heads can become the bottleneck, restricting airflow and capping what the turbo can deliver.

They also take the punishment. Higher heat and pressure are exactly what warp heads and kill gaskets. On a turbo build, head condition is not a detail. It is the foundation.

Warning Signs of a Failing Head or Gasket

Head and gasket problems announce themselves. Catch them early and the repair stays manageable. Ignore them and the bill changes category.

  • Overheating. A compromised gasket can no longer seal the combustion chamber, and temperatures climb.
  • White, sweet-smelling exhaust smoke. That is coolant burning in the cylinders.
  • Coolant loss with no visible leak. The coolant is going somewhere — into the combustion chambers.
  • Milky oil. Oil and coolant mixing looks like a chocolate milkshake on the dipstick or under the oil cap.
  • Rough running and power loss. A poor seal costs compression, and compression is power.

Why Aluminum Heads Warp

Subaru boxer engines are all-aluminum. Aluminum saves weight and sheds heat well. It also expands and contracts more than cast iron as temperatures cycle. That movement works the head gasket constantly — the gasket has to hold a perfect seal between head and block through all of it.

Overheating is the number one cause of gasket failure. Get the engine hot enough and the aluminum head warps. A warped head gives the gasket an uneven surface it cannot seal. Turbo models run higher exhaust gas temperatures, so the margin is thinner.

A warped head can often be machined flat. A "tunneled" head cannot. Tunneled damage comes from extreme, prolonged overheating: the aluminum physically deforms and a channel opens between passages, such as coolant and oil. That is structural failure. The head is done.

What a Blown Gasket Does to the Bearings

A blown gasket between a coolant passage and an oil passage puts coolant in the oil. Coolant-contaminated oil cannot maintain the film that separates metal parts. Bearings are the first to pay for it — they wear fast, and a spun bearing is usually the end of the engine.

That is why a failing gasket is not a "watch it" problem. Stop driving the car. Continued driving turns a gasket job into warped heads, and warped heads into a destroyed bottom end.

Valve Problems Look Like Power Loss

Stock valves are built for a stock engine. Push power up and they become a weak link. Valve float at high RPM — the valves not closing fast enough — and poor valve sealing both cost compression. The symptoms are a rough idle, misfires, and an engine that feels flat.

The fix is valvetrain: higher-quality valves, stronger springs, and lightweight retainers, matched to the build.

What It Costs

Three things set the bill: the parts, the labor, and whether you repair or replace and upgrade.

Head gasket repair: typically $1,000 to $2,000. Most of that is labor — the engine needs significant disassembly to reach the gaskets.

OEM replacement heads (parts only): a standard head runs roughly $200 to $800 depending on the model. A 2.5L SOHC head for a Forester or Impreza is typically around $565. The more complex 2.5L DOHC head for a turbo model like the WRX is closer to $665. Rare or specialized models run higher. Gaskets, bolts, and the small parts are on top of that.

Labor: replacing cylinder heads takes a skilled mechanic 6 to 15 hours. A professional replacement, parts and labor together, often lands between $4,100 and $4,900.

One budgeting fact worth knowing: if the engine is already apart for a gasket job, the expensive part — teardown and reassembly labor — is already being paid for. That is the cheapest moment to upgrade heads instead of reinstalling stock ones.

Rebuild, Resurface, or Replace

These are different operations, and they solve different problems.

  • Resurfacing restores a flat, true sealing surface on a head that has warped. It does nothing for airflow.
  • Porting reshapes the intake and exhaust ports to improve airflow. It does nothing for a warped sealing surface.
  • A rebuild services the head you have: valves refaced or replaced, seats cut, guides and seals renewed, the deck checked and corrected.
  • Replacement is the answer when the head is cracked, tunneled, or worn past what machining can recover.

A resurfaced, rebuilt head is not a remanufactured one, and the terms are not interchangeable. A rebuild services your own casting. A remanufactured head is an existing casting that has had every wear component serviced or replaced to a specification — it is still an original casting at its core, not a newly cast part. Know which one you are paying for.

Diagnosing Head Problems

Two tests settle most questions.

A compression test measures pressure in each cylinder and shows whether a poor seal is costing power. A leak-down test is more precise: each cylinder is pressurized with compressed air, and where the air escapes tells you whether the leak is rings, valves, or the head gasket.

The visual checklist comes first and costs nothing: watch the temperature gauge, look for white exhaust smoke, check for milky residue under the oil cap or in the coolant reservoir, and note rough running or power loss.

If the engine overheats, stop driving and get it checked. Only an inspection — including checking the heads for flatness — can confirm whether you need a gasket, a resurface, or a replacement.

Decoding Casting Codes: B25, D25

On an EJ build you will run into casting codes like B25 and D25. They identify specific versions of Subaru cylinder heads, and the code is stamped directly on the head.

Two rules. Always run a matching pair — a B25 on one side and a D25 on the other creates an unbalanced engine and real performance problems. And respect the RH and LH markings, which denote right-hand and left-hand sides for installation.

Upgrading for More Power

Bare vs. Complete Heads

Bare heads are raw castings — a blank slate. They suit experienced builders who want to select every valve, spring, and retainer themselves, and who can do the assembly correctly.

Complete heads arrive assembled, with components matched and tested to work together. They remove the incompatibility risk and most of the labor. For most builds, a complete, pre-configured package is the right call.

Porting and Valve Jobs

CNC porting uses a computer-controlled machine to reshape and smooth the intake and exhaust ports, removing casting flaws and giving air a cleaner path. A multi-angle valve job cuts distinct angles on the valve seat so air and fuel enter the cylinder with less turbulence.

Crawford's Street Spec heads combine a 3-angle valve job, professional resurfacing, and upgraded valve guides, and are built to support up to 500 whp. Crawford's machine shop services go further, including a 5-angle valve job for builds that call for it.

Valvetrain

Larger, lighter valves — in materials such as stainless steel or Inconel — improve airflow and heat resistance. Stronger springs and lightweight retainers prevent valve float at high RPM. Cam profile has to match the heads and the turbo setup; the combination is the system, not the individual parts.

After any head upgrade, a professional tune is mandatory. The engine breathes differently, and the ECU has to be recalibrated for it — air-fuel ratios, ignition timing, boost, and the AVCS all have to match the new airflow. Without the tune you get neither the power nor the protection. Crawford does not sell tuning; budget for a professional tune as part of the job.

MLS Gaskets and Head Studs

Two supporting parts are non-negotiable on a performance build.

MLS (multi-layer steel) gaskets are built from multiple layers of steel. They withstand the heat and pressure of a turbocharged engine far better than a traditional composite gasket.

Upgraded head studs provide the clamping force that makes the gasket work. Stock head bolts are torque-to-yield — designed to stretch on installation, not reusable, and not strong enough for raised cylinder pressures. Studs deliver more accurate, even clamping across the head and keep it from lifting under boost.

Street vs. Race Spec

A street setup balances power, drivability, and reliability — the build you can drive to work on Monday. A race spec head is built for maximum airflow and peak power at high RPM: aggressive porting, oversized valves, high-lift camshafts. The trade is low-end response. Pick based on how the car is actually used.

Which Models Need the Most Attention

WRX and STI. These cars get driven hard, and power builds raise heat and pressure past what factory heads were designed for. For builds aiming at up to 500 whp, upgraded heads are a reliability part as much as a power part.

Forester and Crosstrek. Off-roading loads an engine differently: long climbs, rough terrain, and heavy loads hold temperatures up for extended periods. Standard heads are designed for daily driving, not sustained trail strain, and wear accelerates accordingly.

Across the lineup, the pattern is the same: head gasket failures, overheating damage, and valve problems follow sustained heat and pressure, whatever the model.

OEM vs. Aftermarket

OEM heads are mass-produced to be cost-effective and reliable at stock power. Within stock parameters, they do their job.

Aftermarket heads are built to exceed those limits — better airflow, better heat handling, more durability under stress. If the engine stays stock, OEM is a straightforward replacement choice. If the engine is modified or will be, the factory compromise becomes the liability, and aftermarket is the honest answer. A well-engineered aftermarket head is more reliable than a stock head in a modified engine, not less.

On warranty: OEM parts carry a factory warranty that typically assumes the rest of the engine is stock. Quality aftermarket parts carry their own warranties. Either way, the long-term value comes from durability and correct installation — flatness checked, seal right, tune done.

Crawford Cylinder Head Packages

Crawford sells complete head packages so the components are matched before they reach your engine, instead of pieced together and hoped over.

The cylinder head packages are tiered — Rebel, Bandit, and Outlaw — each a complete solution built for a specific power goal. The Street Spec cylinder heads carry the 3-angle valve job, professional resurfacing, and upgraded valve guides described above, and support WRX and STI builds up to 500 whp.

Crawford offers built and BTO (Better Than Original) head packages, plus machine shop services including the 5-angle valve job. On the engine side, every Crawford build starts from a brand-new OEM block — no core required or needed. Browse the full range under WRX upgrades.

Professional installation is not optional on head work. The job needs calibrated torque wrenches, correct bolt sequences, and feeler gauges to verify flatness. Uneven torque leaks. A warped surface that gets missed guarantees failure. Crawford's heads carry a 1-year / 12,000-mile warranty, contingent on professional installation — it is the only way to ensure the assembly meets specification. Questions: (855) 677-8243.

Maintenance That Protects Heads

The cooling system is the first line of defense. Maintain it, use quality coolant and oil, and watch the temperature gauge. Check coolant level regularly and look for leaks in the engine bay.

If the engine overheats, pull over and shut it off. Driving even a short distance on an overheating engine is how a manageable problem becomes a warped or tunneled head.

Last, match the part to the car: an FA head does not fit an EJ engine, and the right head for a daily driver is not the right head for a track car. Define the goal first, then buy.

Frequently Asked Questions

What are the first warning signs of a cylinder head problem? Rising or spiking temperatures, white sweet-smelling exhaust smoke, and a milky, frothy substance under the oil cap — coolant and oil mixing. Coolant loss with no visible leak belongs on the same list.

Is upgrading cylinder heads worth it on a street car? Yes, if the car is modified. Add a turbo or exhaust work and stock heads become a bottleneck that limits power and adds stress. A street-focused upgrade strengthens the foundation and returns a gain you can feel daily.

Why is a tune critical after installing new heads? New heads change how the engine breathes. Without recalibration, air-fuel ratios and ignition timing are wrong for the hardware — you lose the power benefit and risk real engine damage.

Can I put heads from a newer WRX on my older STI? No. EJ and FA engines are fundamentally different designs. Bolt patterns, port shapes, and chamber designs are specific to each family. Buy for your model, year, and engine series.

What is the real difference between street and race heads? Purpose. Street spec improves power while keeping daily drivability. Race spec maximizes airflow and peak high-RPM power for a dedicated track build, and gives up some low-end responsiveness to do it.
