FA20 vs EJ25 Engine: The Definitive Guide
Share
The FA20 and the EJ25 are both turbocharged Subaru boxer fours. They are not the same engine in different clothes. The EJ25 is the older design — port injection, a timing belt, and decades of development behind it. The FA20 is the modern one — direct injection and a timing chain. Neither is simply "better." Each has known weak points, and each fails in its own way when pushed past them. Pick based on the car you have and what you plan to do with it.
What they share: the boxer layout
Both engines lay their pistons flat, moving horizontally instead of up and down. The block sits low in the engine bay, which lowers the car's center of gravity and reduces body roll. Opposing pistons cancel each other's primary vibration, so neither engine needs balance shafts. That foundation is the same. Everything above it differs.
Two eras
The EJ family first appeared in 1989. The EJ25 powered the US-market WRX STI from 2004 through the final 2021 model, and it built a deep aftermarket over that run. The FA20DIT (Direct Injection Turbo) debuted in the 2015 WRX with a different set of priorities: efficiency, throttle response, and a wider usable powerband. Crawford builds both platforms.
Fuel delivery: direct vs. port injection
The EJ25 uses port injection. Fuel sprays into the intake ports, just before the cylinder, and washes over the back of the intake valves on its way in.
The FA20 uses direct injection. Fuel sprays straight into the combustion chamber. The burn is more precise, fuel economy improves, and the engine responds earlier in the rev range. The trade-off is real: fuel never touches the intake valves, so nothing cleans them. Oil vapor from the crankcase bakes onto the valves as carbon buildup, and airflow suffers over time. A walnut blasting service every 40,000 to 60,000 miles removes it.
One exception worth knowing: the FA20 in the BRZ and its Toyota counterparts uses a dual-injection system that combines port and direct injection. Under light load the port injectors wash the valves; under load the system switches to direct injection. That version largely avoids the carbon problem.
Timing: chain vs. belt
The FA20 runs a timing chain, housed inside the engine and designed to last the life of the vehicle.
The EJ25 runs a timing belt. It is a wear item with a replacement interval of around every 100,000 miles. This is not optional maintenance. If the belt fails, pistons collide with valves and the engine is done. On a used EJ car with no service record, the belt is the first job.
Internals and turbo behavior
The EJ25 uses a conventional connecting rod. The FA20 uses an asymmetrical rod, shaped to handle the loads direct injection creates, and a longer stroke for torque without a larger block. Different designs, same outcome: the stock rods are a weak point in both engines once power climbs past basic bolt-ons.
The FA20 got a new cylinder head design with better airflow than the EJ, and cast aluminum pistons with a crown shape matched to the direct-injection spray pattern.
The turbos shape how each engine feels. The FA20 uses a twin-scroll turbo. It spools quickly, lag is minimal, and the powerband is smooth and linear. The EJ25 delivers the older pattern: noticeable lag, then a hard surge. Stock output is close on paper — 268 horsepower for the FA20 in the WRX, around 310 horsepower for the EJ25 in the STI — but they do not feel alike.
EJ25 weak points
Head gaskets. The best-known EJ failure. The gaskets seal oil and coolant passages between the block and the heads. Overheating, age, and high cylinder pressure kill them. The signs are unexplained coolant loss, rising temperatures, and white, sweet-smelling exhaust smoke.
Ringlands. The part of the piston that holds the rings cracks under heat, pressure, and detonation. The result is lost compression in that cylinder, a rough idle, a knock, and a rebuild.
Oil consumption and bearings. Crankcase vapor routes back into the intake on a stock EJ, lowering the oil level and contaminating the charge, which raises knock risk. Bearings can starve in hard corners when oil sloshes away from the pickup. Low oil plus hard driving is how these engines die.
The fixes are known: maintenance on schedule, a healthy cooling system, an air-oil separator to keep oil out of the intake, and forged internals when the power goal demands them.
FA20 weak points
Connecting rods. The stock rods reliably handle about 350 ft-lbs of torque. Past that, with aggressive tuning or a larger turbo, they are the first part to fail. Forged rods and pistons are the price of going further.
Carbon buildup. Covered above. It is a maintenance item, not a defect — plan on walnut blasting every 40,000 to 60,000 miles.
Driving habits. Lugging is the fastest way to hurt this engine. Accelerating from 2,000 RPM in sixth gear loads the rods at exactly the wrong moment. Downshift.
Oil. Driven hard, the FA20 consumes oil. Let the level drop and the bearings pay for it. Check it, and run an air-oil separator to manage blow-by.
Maintenance numbers that matter
Forget the factory 6,000-mile oil interval on a turbocharged engine driven hard. Change oil and filter every 4,000 miles or four months, whichever comes first, with high-quality synthetic. Heat and pressure break oil down faster than the factory schedule assumes.
On the EJ25, add the timing belt at around 100,000 miles and keep the cooling system healthy — coolant level, hose condition, temperature gauge. Overheating is the root of most EJ head gasket failures.
On either engine, an air-oil separator is the single most useful reliability part. It strips oil mist out of the crankcase vapor before that vapor reaches the intake, which keeps the intake tract clean, keeps octane where it belongs, and lowers knock risk. Crawford developed the original closed-loop Subaru AOS. It returns the oil to the engine instead of venting it, and it never needs emptying.
Building either engine
Stock limits are stock limits. Past them, the engine has to be built, and the build has to address the weak points above instead of ignoring them.
Every Crawford motor starts from a brand-new OEM block. No core is required or needed, and no build starts from a used case. CrawfordSPEC JE forged pistons are standard where the build calls for forged pistons. Short blocks and long blocks are both available, and Crawford-built long blocks ship free.
For the FA20, the Crawford built FA20 DIT short block is rated at 660 hp, with the rods and pistons to match the platform's known limits.
For the EJ, the current line is rated by name: CrawfordSPEC CSS 540 (450 whp / 540 bhp), Club Racer CCR 660 (550 whp / 660 bhp), and Racer Spec CRS 720+ (600+ whp / 720+ bhp). The legacy stage-named blocks are what they are: the S2 (450 whp), the S3L-X (550 whp), and the S3L-X FSR (600+ whp).
Built engines carry a 1-year / 12,000-mile warranty. Break-in is part of the deal, not a suggestion: oil changes at 500 and 1,500 miles; engine speed kept between 2,000 and 4,500 RPM and varied, with no sustained cruising and no full-throttle pulls; no more than 80% of target boost until break-in is complete. The first oil analysis is mandatory — it is a warranty condition.
Any build, on either platform, ends with a professional tune matched to the parts. Hardware without calibration is how stock engines and built engines both fail.
The bottom line
For a daily driver that stays near stock, the FA20 is the easier engine to live with: better economy, no belt service, power delivered early. Its costs are carbon cleaning and a hard torque ceiling on stock rods.
For a high-power build, the EJ25 is the proven route — the knowledge base and the parts catalog are decades deep — provided the head gaskets, ringlands, and oiling get addressed in the build instead of after the failure.
Both engines are reliable when their weak points are handled first and power is added second. Both are expensive when it's done the other way around.
