FA20 DIT Engine: A Guide to Mods, Tuning & Power
Share
The FA20 DIT is the 2.0-liter direct-injection turbo boxer in the 2015–2021 WRX. Subaru also put it in the 2014–2018 Forester XT. It is a different platform from the EJ engines in the older WRX and STI, with its own strengths and its own limits. Modifying one well means knowing both before you spend anything.
The engine
Four cylinders, laid flat. Dual overhead cams with Dual AVCS — variable valve control on intake and exhaust. Bore and stroke are both 86mm, a square design. Compression is high for a turbo engine at 10.6:1, which is part of why it responds the way it does down low.
The turbo is a twin-scroll. Exhaust pulses are split into two paths so cylinders firing at different intervals don't interfere with each other. The turbo spools sooner, and the engine makes its torque early: 268 hp and 258 lb-ft from the factory, most of it usable in daily driving. The design landed on Ward's 10 Best Engines list two years running.
It also uses a timing chain, not a belt. The belt service older Subaru owners know — roughly every 100,000 miles — doesn't exist here. The chain is built to last the life of the engine.
What the stock engine can take
A stock FA20 DIT, maintained and tuned conservatively, can handle around 400 whp. That is the ceiling, not a target to lean on.
The weak point is the stock connecting rods. The working limit for the factory rods is about 350 ft-lbs of torque. Past that, bent rods and a destroyed engine are real outcomes. The stock cast pistons have their own limit: ringland failure — cracked piston ringlands under cylinder pressure — becomes a risk past roughly 350 whp, especially with knock in the picture.
A tune doesn't change those parts. What a good tune does is keep the engine under the limits with margin: fueling, timing, and boost managed for the fuel you're actually running, with knock protection intact. When you talk to a tuner, that is the conversation — your power goal, the torque it makes, and how much headroom stays in the engine. If a tuner wants to chase a number past the rod limit on a stock bottom end, find a different tuner.
First modification: an air/oil separator
Direct injection sprays fuel straight into the cylinder. Nothing washes over the intake valves, so oil vapor from the crankcase bakes onto them as carbon. Airflow suffers, then drivability does. This is the FA20's most predictable problem, and it starts on a stock engine.
An AOS separates that oil vapor out of the crankcase ventilation stream and returns the oil to the crankcase instead of the intake. Crawford developed the original closed-loop Subaru AOS; it is the first thing we would put on this engine, before any power mod. One caution: Crawford's AOS carries no CARB EO, so check EO status if your state requires one.
An AOS prevents most buildup; it doesn't remove what's already there. If the valves are already coked, walnut blasting is the standard cleaning service, and it's typically needed every 30,000 to 60,000 miles depending on how the car is driven.
Past the stock limits: the built motor
If your goal runs past what the stock rods and pistons can hold, the answer is a built bottom end, not a braver tune.
Crawford's FA20 DIT short block is rated at 660 hp. Every Crawford motor starts from a brand-new OEM block — no core is required or needed, and no build starts from a used case. The pistons are CrawfordSPEC JE forged pistons, made by JE Pistons. Forged internals are what move the ceiling: the rods and pistons that fail first in a stock engine are replaced with parts built for the cylinder pressure.
There are two ways to buy in. A built or BTO short block reuses your heads. A long block adds the heads and valvetrain, assembled — the drop-in route if your heads are tired or you want the whole engine built in one place. Crawford-built long blocks ship free.
Built engines carry a 1-year / 12,000-mile warranty. The conditions are part of the deal: break the engine in — oil changes at 500 and 1,500 miles, engine speed kept between 2,000 and 4,500 RPM and varied, no sustained cruising or full-throttle pulls, and no more than 80% of target boost until break-in is complete — and the first oil analysis is mandatory. It is a warranty condition, not a suggestion.
The rest of the car
Power past stock finds the next weak parts. The stock clutch is built for factory torque; as torque climbs it slips — revs rise, the car doesn't accelerate to match. Brakes and cooling were sized for a stock car too. None of that argues against building the engine. It argues for planning the whole car instead of being surprised by it, one failure at a time.
Running a modified FA20
- Oil: 5W-30 full synthetic. On a modified engine, change it every 3,000 to 5,000 miles, and check the dipstick every other fuel fill-up. Turbo engines use some oil; catching a low level early is cheap insurance.
- Spark plugs: NGK ILKAR8H6, the specified plug. Consistent spark matters more, not less, once the engine is tuned.
- Fuel: 91 or 93 octane, the best available where you are. This is a high-compression turbo engine; knock starts with cheap fuel.
- Attention: new noises, new vibrations, a change in how it pulls. Caught early, most problems are small ones.
What a build costs
Serious FA20 builds are not cheap, and the honest ranges are wide. Mid-level builds with supporting work typically run $5,000 to $15,000 depending on parts and labor. A max-effort build centered on a built motor runs past $10,000. The expensive way to do it is twice: once on a stock bottom end pushed too far, and again on the engine that replaces it.
