Push a stock engine hard enough and it becomes the limit. The pull is not the problem. The parts inside were never built for it.
A forged short block replaces the factory bottom end with stronger internals. It is the foundation for a build that makes real power and stays together.
What a short block is
A short block is the bottom half of the engine: block, crankshaft, pistons, and connecting rods. A long block adds the cylinder heads and valvetrain on top of that.
A forged short block keeps the same job. It does it with parts built for higher cylinder pressure, more heat, and more boost. For the buyer's view — which block, which route — start with the FA20 short block guide. This guide is about what's inside, and why forged is the dividing line.
Forged vs. cast
Factory internals are cast. Molten metal is poured into a mold and left to cool. It is cheap to make in volume and fine at stock power. It can leave small voids and inconsistencies in the metal. Those become failure points under stress.
Forged parts start as a solid piece of alloy shaped under extreme pressure. The grain of the metal compresses and aligns. The part comes out denser and stronger.
That difference is the whole reason for the upgrade. More power means more stress on pistons and rods. Forged parts are built to take it.
Which Subarus use the FA20
The turbocharged FA20 DIT powers the 2015–2021 Subaru WRX. It is the engine most of these builds start with.
The naturally aspirated FA20 powers the 2013–2020 Subaru BRZ, Scion FR-S, and Toyota 86. It has no turbo from the factory. Add one, and the stock internals become the weak point fast.
Crawford builds for both:
- Built FA20 DIT short block (WRX) — CrawfordSPEC JE forged pistons, CrawfordSPEC X-Beam Pauter billet rods, rated to 660 horsepower. $5,999.00 MSRP — product page
- Built FA20 short block, boosted BRZ/FR-S/GT86 — the same CrawfordSPEC internals for the turbo-converted cars, rated to 660 horsepower. $5,999.99 MSRP — product page
- OEM Plus FA20 short block — forged pistons and rods at the stock compression ratio, for the BRZ/FR-S/GT86 that needs strength without a power target. $5,500.00 MSRP — product page
Why the stock block fails
Two failures end most pushed stock engines: cracked ringlands and bent connecting rods.
Both come from the same cause. Cylinder pressure and heat rise past what cast parts were designed for. A larger turbo and an aggressive tune get you there quickly.
A forged short block addresses the cause directly. It replaces the weak cast pistons and rods with forged parts built for that pressure. It does not make the engine unbreakable. It removes the known weak point.
How much power a forged block handles
There is no single number. Capacity depends on the components, the machining, and the assembly — and on the fuel system, cooling, and tune around the block.
The ranges are still real. Stock internals stop being a safe bet north of 350 horsepower. A well-built entry-level forged short block typically handles up to 500 brake horsepower. Crawford's FA20 short blocks are rated to 660 horsepower.
Buy for your actual goal. State the goal first, then choose a block built for it, with headroom. A block run at its limit every day will not last. A block matched to the build, with margin, will.
Do not buy on a headline number alone. Ask what is inside the block and how it was assembled. That is what decides whether it holds.
Reading the specs
Forged pistons
Pistons take the worst of it. Stock cast pistons are brittle under high heat and pressure. Forged pistons use stronger aluminum alloy and hold up.
Crawford's blocks use CrawfordSPEC JE forged pistons. When you compare blocks from any builder, the piston spec is one of the first things to check. It drives strength more than almost anything else in the build.
4032 vs. 2618 alloy
Two alloys cover most forged pistons.
4032 has more silicon. It expands less as it heats, so it can run tighter clearances. It is quieter on cold starts and wears well. It suits a high-performance street car that still has to work as a daily driver.
2618 is stronger under extreme heat and pressure. It expands more, so it needs looser clearances and can be noisy when cold. It suits a dedicated track or race engine.
Neither is better in the abstract. Match the alloy to how the car is actually used.
Bore and compression
Bore is the diameter of the cylinder. On a built block it is honed to a precise finish so the rings seal.
Compression ratio is how much the air and fuel are compressed before ignition. Lower compression is generally safer for a high-boost turbo build. It reduces the risk of knock.
On a built block, bore, compression, piston, and tune have to be chosen together. One spec on its own tells you little.
The deck question
The factory FA20 is an open-deck design. The tops of the cylinders are unsupported. At stock power that is fine. Under high boost, the cylinder walls carry more of the load.
You will see closed-deck conversions sold as the answer. That is not Crawford's route. Every Crawford build starts from a brand-new OEM case and gets its strength from forged internals, upgraded bearings, and blueprinting — the combination rated to 660 horsepower above. Strength from the parts inside, on a case that has never been run.
Rods and studs
Connecting rods link the pistons to the crankshaft. They take enormous load. Stock rods bend or break when power rises. Forged rods are not optional in a built motor. Crawford's are CrawfordSPEC X-Beam Pauter billet rods.
Head studs matter for the same reason. Factory head bolts can stretch under high boost. The head lifts, the gasket fails. Stronger studs hold the clamping force.
Building from parts instead of an assembled block? The internals themselves are in the forged Subaru engine internals collection.
The block itself: new, not seasoned
Crawford built motors start from brand-new OEM blocks. No core is required or needed. No build starts from a used block.
Every FA20 short block Crawford sells is machined, balanced, and assembled from that new block, to order.
How a Crawford block is assembled
Strong parts in a sloppy assembly still fail. Assembly is where a built block earns its price.
CNC machining. The deck is machined flat so the head gasket seals. The cylinders are honed round and straight so the rings seal combustion pressure. A good seal means power is kept and oil consumption stays down.
Balancing and weight-matching. Pistons, pins, and rods are weighed and matched into sets. The crankshaft is balanced with the rotating assembly as one unit. An unbalanced assembly vibrates at high rpm and beats up bearings. A balanced one runs smooth and lasts.
Serial number and build sheet. Every Crawford engine is engraved with a serial number tied to a build sheet. The sheet records the measurements, the parts, and the build. That record follows the engine.
Warranty and break-in
Crawford built short blocks carry a 1-year / 12,000-mile warranty.
Two conditions are not optional. Follow the written break-in procedure. Submit the first oil analysis. Skip either one and you put the warranty at risk.
The confirmed Crawford break-in: oil changes at 500 and 1,500 miles; engine speed 2,000–4,500 RPM, varied — no sustained cruising, no full-throttle pulls; no more than 80% of target boost until break-in is complete; the first oil analysis is mandatory. Break-in seats the new piston rings against the cylinder walls. Do not rush it. A proper seal is what gives you compression, power, and low oil consumption for the life of the motor. Full procedure: Subaru engine break-in for a built motor.
Kit vs. professionally built block
You can buy the parts as a kit, or buy an assembled short block.
A kit looks cheaper. Then add machine work: boring, honing, cleaning, decking, balancing. Add the tools. Add the time. Engine assembly is a game of thousandths of an inch. One mistake can cost you the whole build, with no warranty behind it.
An assembled block includes the parts, the machining, the labor, and the quality control — and a warranty. Compare the full cost of both routes, not the sticker price of the kit.
Supporting modifications are not optional
A short block is one part of a system. Plan for the rest before you buy, not after the block is in.
Fuel. A built engine needs more fuel than the stock system delivers. A higher-flow pump and larger injectors are typical. Starve a built engine of fuel and it runs lean. Lean under boost destroys engines.
Cooling. More power makes more heat. The factory cooling system was sized for a stock engine. A high-performance aluminum radiator is a sensible starting point. Track cars should also run an oil cooler to keep oil temperatures and viscosity stable.
Drivetrain. Power goes through the clutch, transmission, axles, and differential. Stock parts were built for stock torque. An upgraded clutch is the first requirement. Beyond that, it depends on the goal and how the car is driven.
Tune. A professional ECU tune is the final step and it is not negotiable. The tune sets fuel, ignition, and boost for your exact combination of parts. A generic map does not know your build. Do not run a built engine on one. Crawford recommends Delicious Tuning for e-tuning.
Installation
Use a complete installation kit so the gaskets, seals, and hardware are right and on hand — the FA20 kits are in the short block installation kits collection, $699.99 for the FA20 and FA20 DIT versions.
Stock cylinder heads can be reused on a new forged short block. Have them inspected and resurfaced first. The head surface and the deck surface have to meet flat, or the gasket will not seal.
This is precision work in a clean environment. If you do not have the tools, the measuring equipment, and the experience, pay a shop that does. The labor is a small part of the total build cost. A failed assembly is not.
Living with a forged engine
A forged engine does not behave exactly like a stock one.
On a cold start you may hear a light ticking or tapping. That is piston slap. Forged pistons expand more as they heat, so they are fitted with more clearance when cold. The sound fades as the engine warms. It is normal. Let the engine warm up before you drive it hard.
Change the oil more often than the factory interval — every 3,000 miles on a daily-driven forged block is a good rule. A built engine works its oil harder, and more fuel and combustion byproducts get into it. Follow the interval given with your build, and do not stretch it.
Choosing the right block
Decide three things before you spend anything.
Your goal. Daily driver with more power, or a track car? Be honest. The goal picks the block, the alloy, and the supporting parts.
Your total budget. The block is part of the cost. Fuel, cooling, drivetrain, installation, and the tune are the rest. Budget the whole build. A finished, tuned car beats a stronger block sitting in an unfinished one.
Your timeline. Crawford motors are built to order. Factor build time and break-in into the plan.
The common mistakes are simple. Making big power on a stock block until it breaks. Buying a block far beyond the goal and running out of money for the tune. Buying a cheap block with no warranty. Avoid those three and you are ahead of most builds.
If you are weighing a short block against a complete engine, the FA20 long block guide covers the other route. Questions on a build: (855) 677-8243.
Frequently asked questions
Is a forged short block reliable enough for a daily driver? Yes, if it is built correctly and tuned properly. Under normal driving, forged internals are under less stress than stock parts in a stock engine. The supporting systems — fuel and cooling — still have to be right, and the maintenance schedule is stricter.
Do I need one with basic bolt-ons? No. An intake and a cat-back do not need a built block. A forged short block becomes the right spend when you move to a larger turbo or aggressive tuning past what factory internals handle safely.
Short block or long block? A short block is the bottom end only. A long block adds heads and valvetrain. If your heads are sound, a short block replaces the part that actually needs reinforcing, for less money.
Can I reuse my stock heads? Yes. Have them inspected and resurfaced by a machine shop first. For higher-power builds, consider valvetrain upgrades while they are off.
Why does break-in matter so much? Because the ring seal is made then, and it cannot be remade later. Rush break-in and the engine will use oil and lose compression for the rest of its life, no matter how good the parts were.
